Professional FTTH Manufacturing By Shanghai Weiye OFC Equipment
For projects where timing and performance are critical, Shanghai Weiye OFC Equipment delivers customized drop solutions backed by complete test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment matches specialized equipment with tight material control. We offer customized service and products for residential and MDU rollouts. Every order includes 100% quality assurance and complete test reports.
Our lab performs high-temperature, salt spray, and vibration tests to verify durability. Available jacket choices include LSZH, PVC, and PE. Designs cover bow-type flat and self-supporting styles and use brand fibers such as Fujikura and Corning SMF-28e.
- Recorded line controls and production checks support auditable shipments.
- Engineering support for specs, trials, and ramp to volume.
- Updated fixtures and calibrated processes reduce variation so each cable can meet operator standards.
FTTH Cable Manufacturing
At Shanghai Weiye OFC Equipment, manufacturing steps are coordinated to network specifications, combining brand fiber choices with strict test routines.
Selecting Optical Fiber And Brand Options
We select optical fiber to bend radius, attenuation, and deployment type. Available options include OS1, OS2, OM2–OM4, ITU-T G.652D, and G.657.A1/A2. Brand fiber choices, including Fujikura and Corning SMF-28e, are available to satisfy procurement requirements.
Strength Member Integration
Strength member options include dielectric FRP and metallic steel wire. FRP works well where non-conductive cable runs are needed. Steel wire provides extra tensile strength for longer aerial spans and bonding or grounding requirements.
Jacket Extrusion And Process Control
Jacket materials include LSZH for indoor flame safety, PVC for flexible handling, and PE for outdoor UV and moisture protection. Tight process control of temperature and capstan ratios supports line speed and dimensional tolerances.
| Part | Dielectric FRP | Metallic steel wire |
|---|---|---|
| Best use | Non-conductive runs | Long aerial spans, higher tensile needs |
| Main benefit | Low weight and non-reactive | High strength |
| Installation note | Easier terminations | Needs proper grounding practice |
Inline Testing And Final Inspection
Inline geometry and concentricity checks take place during manufacturing. Final optical testing confirms attenuation and return loss. Every order ships with a complete test report plus lab results from high-temperature, salt-spray, and vibration trials to support drop termination and field-use requirements.
Lead times are typically 4–5 days for orders below 100 km and 7–10 days for orders below 500 km. Material lot records and first-article approvals support traceability and compliance for U.S. projects.
FTTH Drop Cable Designs And Structures We Manufacture
Shanghai Weiye OFC Equipment supplies a focused range of drop cable designs for both tight indoor routing and exposed aerial spans. Every option combines tested materials with geometry designed for field termination and stable optical performance.
Bow-Type Flat Cable For Indoor Distribution
Bow-type flat drop cable keeps the footprint small for risers, hallways, and conduit runs. It keeps bend loss low for easy routing in hallways and MDUs.
Self-Supporting Cable Designs For Aerial Spans
Self-supporting FTTH drop designs use a messenger element to handle tensile loading. Dielectric FRP is available for non-conductive routes, while steel wire is suitable when bonding and additional tensile strength are needed.
Strength Member And Core Layouts
We offer dielectric and metallic strength member configurations to match safety and EMI rules. Center loose tube and unitube flat designs balance crush resistance with fiber access for faster termination.
Jacket Choices For Indoor And Outdoor Use
Jacket options include LSZH for flame-retardant, low-smoke indoor applications and PE for outdoor UV and moisture resistance. Every cable family is checked for mechanical and optical quality before shipment.
| Design | Recommended use | Support member | Sheath |
|---|---|---|---|
| Bow-style flat | Indoor risers, MDUs | FRP (dielectric) | Indoor LSZH |
| Aerial self-supporting | Pole-to-premise spans | Steel wire or FRP | PE |
| Center loose tube | Higher-count routes | Dielectric FRP | LSZH/PE |
| Flat unitube | Low-count, easy strip | Dielectric or metallic strength | Indoor/outdoor jacket |
Production Line Equipment For Quality And Speed
At Shanghai Weiye OFC Equipment, automation and sensor-based feedback minimize manual handling while supporting patch cord preparation throughput.
Our production line combines automated machines that cut and strip drop patch cords to raise throughput and cut labor variability.
The CLX-BPO2 auto-stripping machine operates with PLC and photoelectric controls. With a cycle time of about 1.5 seconds, it supports real-world speeds near 20 terminal operations per minute.
Automated Cutting And Stripping For Drop Cable Patch Cords
The equipment can strip LSZH and PVC jackets while trimming FRP or steel strength members to accurate stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and low downtime.
PLC And Photoelectric Control For Precision And Repeatability
PLC logic combined with photoelectric sensors provides accurate positioning and closed-loop control. Inline checks support control charts, helping operators correct process trends before defects increase.
| Feature | Performance | Benefit |
|---|---|---|
| CLX-BPO2 unit | About 1.5s cycle with auto-strip | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinder based | Reliable high-speed actuation |
| Supported materials | LSZH and PVC jackets; FRP and steel strength members | Precise stubs and cleaner prep |
| Process control | PLC + photoelectric + inline checks | Consistent quality, lower rework |
- Automated waste ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Machines, fixtures, and trained staff work together to meet FTTH volume goals while preserving accuracy.
CLX-BPO2 Auto-Stripping Machine Functions In Our Line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase output while standardizing terminal preparation quality. The unit operates at roughly 1.5 seconds per cycle, producing about 20 terminal preparations per minute under production conditions.
PLC and photoelectric controls provide accurate detection and repeatable machine movement. This control helps maintain tight tolerances for strip lengths and reserved strength stubs.
Cycle Time And Production Throughput
Typical operation speed is 1.5s per cycle. That speed translates into steady throughput during continuous production.
Supported Jacket And Reserved Strength Lengths
The CLX-BPO2 can strip LSZH and PVC jackets, with adjustable jacket strip length from 17.5 to 35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to match common termination hardware.
FRP And Steel Wire Strength Member Handling
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Customized cutters are available for nonstandard sizes to preserve precision.
- Automatic waste ejection and sensor-triggered start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight ease integration into workcells.
- Cylinder-driven motion and PLC/photoelectric control improve line reliability and lower maintenance interruptions.
| Spec | Rated value | Benefit |
|---|---|---|
| Cycle speed | ~1.5 s (~20/min) | High throughput for production runs |
| Jacket strip lengths (A) | 17.5 mm to 35.0 mm | Supports common connector prep |
| Strength stub (B) | 7.0 mm to 11.0 mm | Supports strength and termination requirements |
| Electrical and size data | Compact 110–220V, 50W machine | Fits existing production equipment easily |
By using this machine, Shanghai Weiye OFC Equipment standardizes preparation so field teams receive drop components ready for fast installation. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Custom Specifications To Match Your FTTH System
Shanghai Weiye OFC Equipment customizes each build to match network requirements and make field rollout easier. Clear options and predictable manufacturing windows help your teams receive products that are ready to install.
Cable Core Counts, Fiber Types, And Colors
Select 1–4 core designs using single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D and G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tagging.
Jacket Materials, Print Legends, And Branding
Select LSZH, PVC, or PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Length Choices, Packaging, And Custom Structures
Standard put-ups are 1 km, 2 km, and 4 km with tailored reels and packaging to suit storage and handling. Bow-type flat or self-supporting designs can be paired with steel wire or FRP strength members to match span, bonding, and isolation requirements.
| Option | Typical choice | Result |
|---|---|---|
| Length | 1 km, 2 km, or 4 km | Less staging, easier reels |
| Sheath | LSZH, PVC, or PE | Indoor/outdoor compatibility |
| Design type | Bow-type flat or self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye matches runs to your schedule and delivers documentation that lists final specifications for straightforward QA on site.
Testing, Documentation, And Quality Assurance
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item ships with recorded acceptance data.
High-Temperature, Salt Spray, And Vibration Lab Tests
Our lab runs high-temperature exposure, salt spray corrosion, and vibration tests to qualify materials and assemblies. These tests recreate field stresses for indoor and outdoor use.
100% Test Reports For Every Cable
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection checkpoints prevent nonconforming items from leaving the factory.
Traceability And Compliance
Batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation can follow common customer templates to speed approval and inbound inspection.
- Line checks and final inspection prevent field failures and lower warranty events.
- QA packages include specifications confirmation and formatted test data for rapid review.
- Continuous test trends inform preventive maintenance and improve long-term reliability.
| Test | Reason | Verified outcome |
|---|---|---|
| High-temperature | Thermal material stability | Validated heat endurance |
| Salt-spray corrosion | Resistance to corrosion | Outdoor suitability |
| Vibration | Mechanical robustness | Lower failure risk |
FTTH Drop Cable Pricing And Cost Drivers
Planning the budget for a drop cable run begins with fiber and jacket choices, then adjusts for volume and customization.
Pricing can vary widely, from about $30 to $1,000 per unit, depending on fiber grade, jacket material, length, and structure.
Material Choices, Fiber Grade, Jacket Type, And Structure
Main cost drivers include fiber optic grade, jacket material, and the cable structure selected for deployment.
Self-supporting designs and steel reinforcement can increase material and labor requirements. Custom colors, logos, and print legends may add setup time and affect pricing, especially for short runs.
Order Length, Volume, And Customization Impact On Price
Longer reel lengths and larger-volume orders usually reduce unit cost. Small quantities often carry setup fees and higher per-unit charges.
- Changeovers and special cutters increase lead time and add to cost.
- Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets across phases.
| Pricing factor | Effect on price | Recommendation |
|---|---|---|
| Optical fiber grade | Strong influence | Match performance to budget |
| Sheath material | Moderate impact | Compare LSZH vs. PE for total cost |
| Order length / volume | Large impact | Combine orders where practical |
Lead Time, MOQ, And United States Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable delivery windows help reduce downtime and control costs during active rollouts.
Production Windows And Capacity Planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We schedule line capacity to match your rollout milestones and to keep deliveries on time.
The service team provides production updates and tracking details so installers know when reels will arrive. For urgent schedules, contingency capacity can help accelerate critical-path orders.
MOQ And Why It Matters
The MOQ is 1 km. This reflects setup needs such as wire and jacket die adjustments that consume start-up material and scrap.
We review your length and staging plans to choose reel sizes that cut waste and handling. Batch releases can balance inventory holding with frequent, smaller deliveries to job sites.
Installation Preparation And Application Scenarios
Site conditions dictate whether a self-supporting span, duct pull, or direct-buried run is the best fit for a project.
Aerial, Duct, And Direct-Buried Installation Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to control sag and tension for long-term reliability.
Duct installations perform best with low-friction jackets and crush-resistant constructs so pulling does not damage fibers. PE jackets are commonly used for underground and buried routes where moisture resistance is important.
Direct-buried designs need proper burial depth according to local codes and moisture-resistant jackets to protect the optical core over time.
Indoor Riser And Plenum Distribution With ONT Termination
Indoor riser and plenum routes usually use LSZH jackets to satisfy flame and smoke requirements. Flat drop cable forms strip cleanly and present controlled strength stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware compatibility. Standardized prep from the production line shortens install time and reduces scrap.
| Application | Main feature | Field note |
|---|---|---|
| Aerial span | Self-supporting strength member | Check tension and messenger hardware |
| Duct | Pull-friendly jacket and crush protection | Use correct pull tape and lubricant |
| Direct-buried | Moisture-resistant PE jacket | Observe burial depth and warning tape rules |
| Indoor | LSZH jacket, tight bend support | Protect bend radius through penetrations |
Our approach ensures a consistent install experience across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and reliable field performance for your system.
End-To-End Support And After-Sales Assistance
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment supports engineering from initial requirements through approved drawings and pre-production builds. Documentation templates and clear installation notes help field crews work from a consistent plan.
After-sales support includes rapid response, root-cause analysis, and corrective action. Every product ships with full test reporting and traceability to support QA acceptance.
- Round-the-clock availability supports status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Line schedule coordination helps handle urgent changes and acceleration requests.
- Configuration control helps ensure shipped items match agreed requirements each time.
| Service area | Support provided | Result |
|---|---|---|
| Spec engineering | Drawing review and trial production | Fewer field issues |
| Quality testing | Laboratory trials and complete test reports | Auditable quality records |
| After-sales service | Corrective action and replacement support | Faster issue resolution |
Final Thoughts
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We deliver customized ftth drop solutions that pair material choices with validated manufacturing and lab testing. Every reel ships with a 100% test report and documented trials to support field acceptance in the United States.
A strong production line, including CLX-BPO2-enabled preparation machines, reduces variation and improves turnaround. Our equipment standardizes strip lengths and strength stubs so installers receive consistent results during turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to support longer service life. Dedicated support guides scheduling, logistics, and after-sales care so your deployment stays on plan.
Contact Shanghai Weiye OFC Equipment to coordinate specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
