QUALITY CONTROL METHODS FOR OPTICAL FIBER RIBBON MANUFACTURING

Understanding the intermittent bonded ribbon production line

Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. supplies equipment for producing rollable formats used in optical-fiber manufacturing. Buyers can compare the capacity of this setup against their intended product range because it is designed for 12- and 16-fiber ribbons. Its split-type construction may also affect factory space and installation requirements.

Fiber Secondary Coating Line
FTTH Cable Production Line
Fiber Secondary Coating Line

For this specific production line, the specified construction speed is 600 m/min. Fiber pay-off, gathering and guiding, intermittent resin dispensing, UV-LED curing, visual monitoring, capstan pulling, and take-up are combined in the process. The complete process is important to evaluate, not just the stated speed.

Before purchasing, review factory utilities, reel requirements, available floor space, and installation conditions. Ask the supplier for its documentation package and check the system’s suitability for your cable design and operating requirements. Addressing these details in advance may reduce setup delays and support a smoother start.

Main Takeaways

• Designed for rollable 12- and 16-fiber formats.
• Specified equipment speed: 600 m/min.
• Uses a split-type construction.
• Includes curing, monitoring, pulling, and take-up stages.
• Before purchasing, verify utilities, reels, installation requirements, and supplier documentation.

Intermittent Bonded Ribbon Production Line

Explore The Intermittent Bonded Ribbon Production Line

Three mold groups help shape rollable IBR formats by positioning fibers for small adhesive dots. Mold position is adjustable by operators from 0 to 15 mm, helping maintain consistent spacing and form.

Produce Rollable Fiber Ribbons With Precision Bonding

The machine is supplied by a 16-spool pay-off, and guide rollers with U-shaped grooves help maintain the organization of each strand. Hard-anodized roller surfaces support steady contact during processing. For 12F and 16F layouts, the adjustable valve setup uses 5+5+1 valves for 12 fibers or 5+5+5 for 16. Ask the supplier to confirm tension control settings that suit your particular cable design.

Support 12- And 16-Fiber Configurations At Speeds Up To 600 m/min

The stated construction speed is up to 600 m/min. Pay-off reel options hold 25.2 km or 50.4 km of fiber according to the listed reel dimensions: Φ236 mm × Φ25.4 mm × 108 mm and Φ267 mm × Φ25.4 mm × 180 mm. T-type and fiber-optic take-up reels are also offered for this system. Compare reel capacity with your operational requirements and expected changeover time.

Examine The Production Line’s Main Equipment And Controls

Tension, resin placement, and UV exposure must work together to deliver reliable output. Operators can use the system to match settings with the needs of their cable design and fiber ribbon.

Coordinate Fiber Tension, Resin Dispensing, And UV-LED Curing

Every pay-off unit uses electro-pneumatic adjustment. Dispensers can run independently or in linked groups, with adhesive-dot spacing and counts configured through the interface.

Three pre-curing ovens serve the mold groups ahead of UV-LED post-curing. Verify resin compatibility and operating conditions with the supplier.

The Siemens PLC and touchscreen show lamp current and oven temperature, generate alarms, and support preset lengths. Check the necessary cabinet and power supply arrangements before purchasing.

Process Stage	Technical Specification	Buyer verification
Fiber tension	Pay-off: 0.4 to 2 N, ±0.02 N; capstan: 50 to 500 g, ±5 g accuracy	Align settings with cable requirements
Resin dispensing	Independent or linked units; set adhesive-dot spacing and count	Review interface settings
UV-LED curing	Three 800 W pre-curing ovens; one 6 kW post-curing oven; 395 nm ± 3 nm; at least 85% cure under stable, high-speed conditions	Verify compatibility with the resin
Process monitoring	Siemens S7-1200 or S7-1500 PLC; 10.4-inch touchscreen; real-time lamp current and oven temperature, alarms, preset lengths	Check cabinet and power supply

Prepare Line Configuration, Installation, And Operating Conditions

Before the machine is delivered, set aside a dedicated operating area. An enclosed, clean, dry, draft-free space is needed for the optical fibre system. Maintain temperatures between 15°C and 25°C and humidity at or below 85%. Maintaining these conditions supports equipment protection and operating precision.

With your facilities team, check site utilities, available electrical capacity, cabinet space, and cable design. The system needs nitrogen supplied at 7 bar and 99.99% purity, together with compressed air at 6 bar. The electrical supply must be three-phase, five-wire, and 380 V ±10%.

• Allow space for the cabinet, components, resin, and access to service parts. Verify temperature settings and tension control before startup.
• Plan around the specified reel dimensions of Φ410 mm × Φ50.8 mm × 391 mm. The take-up unit accepts reels weighing up to 30 kg.
• Account for the main power feed-in cable when planning the site. The equipment package excludes connection cables and cable trays.

Before ordering, confirm the supply scope, reel types, and installation requirements. This assessment can reduce setup time and help prevent later delays. Ask the supplier to verify settings for your fiber and cable design, including lamp accuracy and operating conditions. Clear planning enables a smoother startup for the production system.

Request Pricing For A Ribbon Production Solution Tailored To Your Needs

At its stated speed of 600 m/min, this line can be assessed by manufacturers producing rollable 12- or 16-fiber formats. When requesting a quote, share your fiber layout, output goals, cable requirements, reel preference, and factory conditions.

Check the proposed system for its 16-spool pay-off, UV-LED curing setup, take-up capacity, and available options. Examine the included components, dispensing-head options, unit functions, and cable design prior to ordering.

Listed documents include operating and maintenance manuals, a general layout drawing, electrical schematics, and a wear-parts list. These documents can help understand setup time and ongoing service needs.

Contact Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. to obtain pricing and configuration details that suit your output plan and site utilities. Before buying, confirm the scope of supply and replacement parts.
